specifications

Electronics

Battery: 17Ah/17.5Ah

Charger: 48V 2 amp, operates on both 110V and 230V AC power outlets

Motor: 250W brushless geared rear hub motor, 48V

Pedal assist: 7 level power assist with integrated cadence sensor, supports to 25 km/h (15 mph). Walk assist 6 km/h (3.7 mph)

Controller: 250W, 48V, 18A

Display: Smart LCD color display that shows all data needed, including battery and pedal assist level. Integrated 5V charging port.

Wiring: Plug & Play system for easily servicing worldwide

Braking system

Brake callipers: TEKTRO hydraulic, strong braking power with pinpoint modulation

Rotors: 160 mm aluminium front and rear, reliable braking surface

Additional components

Handlebar: 620 mm wide, 31.8 mm clamping area, 5 ° ergo bend

Grips: Anti-slip ergonomic grips

Seatpost: 33.9 mm x 450 mm

Saddle: Comfortable, durable imitation leather with ergonomic cut-out

Bottom bracket: 164 mm, square taper

Drivetrain

Shifter: 8-Speed Revohift twist shifter for smooth, crisp shifting between gears

Derailleur: 8-Speed

Crankset: 170 mm alloy, 53-tooth, 5-bolt chainring

Freewheel: 8-Speed, 13-32T

Chain: 6061 Aluminium alloy with folding lever, 2.7 kg (6 lbs)

Frameset and suspension

Frame: 6061 Aluminium alloy with folding lever, 2.7 kg (6 lbs)

Front suspension: 20″ aluminium alloy spring fork with lockout and preload adjustment 28.6 x 25.4 x 185mm

Rear suspension: Pre-adjusted suspension 150L x 650B 24 x 33

Geometry and rider specs

Weight: 28.5 kg

Folded: 78 cm high, 103 cm long, 59 cm wide

Unfolded: 124 cm high, 180 cm long, 65 cm wide

Rider weight max: 150 kg
